SMLS pipes and welded pipes serve different roles in industry:
-
Seamless pipes: higher cost but superior strength, uniformity, and high-pressure suitability
-
Welded pipes: tiết kiệm chi phí, suitable for low to medium-pressure applications
Both types are available in standard nominal sizes, độ dày của tường, và độ dài, making them adaptable for a wide range of công nghiệp, cấu trúc, và ứng dụng cơ khí.
Yêu cầu nhanh
- Sự miêu tả
SMLS Pipe, hoặc Seamless Stainless Steel Pipe, is manufactured from solid billets through hot piercing and rolling without any welded seam.
Nó được sử dụng rộng rãi trong high-pressure, nhiệt độ cao, and corrosive environments, such as chemical processing, oil and gas, power plants, and mechanical systems.
Welded stainless steel pipes are made by rolling and welding flat steel plates, which creates a seam along the pipe. Both types have advantages depending on ứng dụng, áp lực , and budget.
Seamless vs Welded Stainless Steel Pipe
| Tính năng | Ống nước liền mạch (SMLS) | Ống hàn |
|---|---|---|
| Manufacturing Method | Hot piercing & rolling from solid billet | Rolled plate welded along seam |
| Wall Consistency | Highly uniform | Slight variation near weld |
| Pressure Resistance | High – suitable for high-pressure systems | Moderate – depends on weld quality |
| Chống ăn mòn | Excellent – no weld seam to corrode | Good – weld may require extra treatment |
| Độ chính xác kích thước | Cao | Vừa phải |
| Trị giá | Cao hơn | Thấp hơn |
| Ứng dụng điển hình | High-pressure, hóa chất, hóa dầu, phát điện | Low to medium-pressure piping, water systems, structural tubes |
Bản tóm tắt: Seamless pipes are preferred for critical systems requiring sức mạnh, uniformity, and high-pressure performance, while welded pipes are cost-effective for low-pressure or non-critical applications.
Common Size Specifications
1. Seamless Stainless Steel Pipe (SMLS)
| Kích thước danh nghĩa (TRONG) | Đường kính ngoài (TRONG) | Độ dày của tường (TRONG) | Chiều dài chung (ft) |
|---|---|---|---|
| 1/2 | 0.84 | 0.065 – 0.109 | 20 |
| 1 | 1.315 | 0.109 – 0.179 | 20 |
| 2 | 2.375 | 0.154 – 0.218 | 20 |
| 4 | 4.500 | 0.237 – 0.337 | 20 |
| 6 | 6.625 | 0.280 – 0.432 | 20 |
OD remains constant per NPS standard; wall thickness depends on số lịch trình (SCH 10, 40, 80, vân vân.).
2. Welded Stainless Steel Pipe
| Kích thước danh nghĩa (TRONG) | Đường kính ngoài (TRONG) | Độ dày của tường (TRONG) | Chiều dài chung (ft) |
|---|---|---|---|
| 1/2 | 0.840 | 0.065 – 0.109 | 20 |
| 1 | 1.315 | 0.109 – 0.179 | 20 |
| 2 | 2.375 | 0.154 – 0.218 | 20 |
| 4 | 4.500 | 0.237 – 0.337 | 20 |
| 6 | 6.625 | 0.280 – 0.432 | 20 |
Welded pipes generally follow the same nominal sizes as seamless pipes but may be limited in high-pressure or thick-wall applications.
Ứng dụng
Seamless Stainless Steel Pipe (SMLS):
-
High-pressure chemical pipelines
-
Oil and gas pipelines
-
Boiler and heat exchanger lines
-
High-temperature service piping
Welded Stainless Steel Pipe:
-
Low-pressure water and steam systems
-
HVAC pipelines
-
Structural and decorative tubing
-
Food and beverage processing lines
