316l Paip Keluli Tahan Karat

316l Paip Keluli Tahan Karat

316L vs 304L Summary

Ciri	316L	304L
Rintangan Kakisan	unggul, terutamanya dalam persekitaran yang kaya dengan klorida	bagus
Kandungan Molibdenum	2–3%	tiada
Kebolehkimpalan	Cemerlang	Cemerlang
kos	Lebih tinggi	Lebih rendah
Penggunaan Biasa	Marin, kimia, farmaseutikal	General-purpose, low-corrosion environments

Bottom Line: 316L is preferred for more corrosive or chloride-containing environments, while 304L is suitable for general industrial and architectural applications.

Penerangan

316L Stainless Steel Pipe is a rendah karbon, austenitic stainless steel pipe digunakan secara meluas dalam kimia, farmaseutikal, makanan, and marine applications.
Its low carbon content (≤ 0.03%) prevents intergranular corrosion after welding, menjadikannya ideal untuk high-temperature and high-corrosion environments.

316L stainless steel provides superior corrosion resistance compared to 304L, terutamanya dalam chloride-rich or acidic environments.

Komposisi Kimia

unsur	316L (%)	304L (%)
Karbon (C)	≤ 0.03	≤ 0.03
Chromium (Cr)	16–18	17–19
Nikel (Dalam)	10–14	8–12
Molibdenum (Mo)	2–3	–
Mangan (Mn)	≤ 2	≤ 2
silikon (Dan)	≤ 1	≤ 1
Fosforus (P)	≤ 0.045	≤ 0.045
Sulfur (S)	≤ 0.03	≤ 0.03
Besi (Fe)	Keseimbangan	Keseimbangan

Molibdenum is the key difference, enhancing resistance to pitting and crevice corrosion, particularly in chloride environments.

Sifat Mekanikal (tipikal)

Harta benda	316L	304L
Kekuatan Tegangan	485–620 MPa	485–620 MPa
Kekuatan Hasil (0.2%)	≥ 170 MPa	≥ 170 MPa
Pemanjangan	≥ 40%	≥ 40%
Kekerasan (HB)	≤ 217	≤ 217
Rintangan Kakisan	Cemerlang (esp. in chloride)	bagus
