Bahan Lembaran Stainless Steel

Stainless steel sheet material is typically produced from coil form, which is then converted into flat sheets through a series of controlled mechanical and thermal processes. This coil-to-sheet workflow is the standard route in modern stainless steel manufacturing, ensuring efficiency, akurasi dimensi, dan kualitas permukaan.

Overview of Coil to Sheet Processing

The transformation from stainless steel coil to sheet includes the following key stages:

1. Coil production (hot rolled or cold rolled)
2. Annealing and surface treatment
3. menggorok (if width adjustment is required)
4. Cut-to-length processing
5. Leveling and flatness correction
6. Inspection and packaging

1. Stainless Steel Coil Production

The process begins with stainless steel coils produced by rolling:

Hot Rolled Coil

• Ketebalan: typically ≥ 3 mm
• Permukaan: rough, skala oksida (Selesai No.1)
• Used for structural and heavy applications

Cold Rolled Coil

• Ketebalan: typically ≤ 3 mm
• Permukaan: mulus (2B, BA, atau dipoles)
• Used for precision and decorative applications

Coils are preferred because they allow continuous processing and flexible downstream sizing.

2. Annealing and Surface Treatment

After rolling, coils undergo heat treatment and cleaning:

• Anil
  • Mengembalikan keuletan
  • Eliminates internal stress
  • Refines grain structure
• Pengawetan
  • Removes oxide scale from the surface
  • Meningkatkan ketahanan terhadap korosi

Optional processes:

• Bright annealing (for high surface quality)
• Surface polishing or brushing

3. Slitting Process (Width Adjustment)

If narrower widths are required, the coil is slit into strips.

Process Characteristics:

• Rotary blades cut the coil longitudinally
• Multiple strips can be produced simultaneously
• High-speed continuous operation

Keuntungan:

• Kontrol lebar yang akurat
• High material utilization
• Suitable for strip production

4. Dipotong menjadi Panjang (CTL) – Core Sheet Conversion

Cut-to-length is the main step in converting coils into sheets.

Process Flow:

1. Penguraian (unwinding the coil)
2. Penyamarataan (removing curvature)
3. Precision cutting to specified length
4. Automatic stacking

Manfaat Utama:

• Custom sheet sizes
• Akurasi dimensi tinggi
• Efficient batch processing

5. Leveling and Flatness Control

Leveling ensures that sheets are flat and stress-free.

• Multi-roll leveling machines are used
• Internal stresses from rolling are reduced
• Wave defects and edge distortion are minimized

Flatness is critical for:

• Pemotongan laser
• Bending operations
• Pengelasan dan fabrikasi

6. Surface Protection and Finishing

To maintain surface integrity:

• Protective films can be applied
• Edges may be trimmed or deburred
• Additional finishes (cermin, disikat) can be processed

7. Final Inspection and Packaging

Before delivery, sheets are checked for:

• Toleransi ketebalan
• Cacat permukaan
• Akurasi panjang dan lebar

Packaging includes:

• Moisture-proof wrapping
• Palletized stacking
• Anti-scratch protection

Parameter Pemrosesan Utama

Keuntungan Pengolahan Coil-to-Sheet

• Flexible size customization
• Efisiensi produksi yang tinggi
• Consistent product quality
• Reduced material waste
• Suitable for large-scale industrial supply
