Drenaje de acero inoxidable
Stainless Steel Drain pipes provide a durable, hygienic, and corrosion-resistant solution for residential, comercial, and industrial drainage systems.
Con standard and custom sizes, and a controlled manufacturing process, they ensure efficient flow, long service life, and reliable installation.
- Descripción
Stainless Steel Drain pipes are specialized stainless steel tubes used for residential, comercial, and industrial drainage systems.
They are valued for their resistencia a la corrosión, durabilidad, and hygienic properties, haciéndolos ideales para wastewater, rainwater, and chemical drainage applications.
Unlike standard structural tubing, drainage pipes often require smooth internal surfaces y dimensiones precisas to ensure effective flow and prevent blockage.
Especificaciones comunes
Stainless steel drains are manufactured in a range of diámetros, espesores de pared, y longitudes, depending on the installation requirements:
Round Drain Pipes (Imperial / Inch Units)
| Tamaño nominal (en) | Diámetro externo (en) | Espesor de la pared (en) | Longitud común (pie) |
|---|---|---|---|
| 1 | 1.315 | 0.065 – 0.109 | 10 – 20 |
| 2 | 2.375 | 0.065 – 0.154 | 10 – 20 |
| 3 | 3.500 | 0.065 – 0.216 | 10 – 20 |
| 4 | 4.500 | 0.120 – 0.337 | 10 – 20 |
| 6 | 6.625 | 0.280 – 0.432 | 10 – 20 |
Metric Drain Pipes (mm Units)
| Nominal Diameter (milímetros) | Espesor de la pared (milímetros) | Longitud común (metro) |
|---|---|---|
| 25 | 1 – 2 | 3 – 6 |
| 32 | 1 – 2.5 | 3 – 6 |
| 50 | 1.5 – 4 | 3 – 6 |
| 75 | 2 – 5 | 3 – 6 |
| 100 | 2.5 – 6 | 3 – 6 |
Custom sizes can also be produced based on project requirements.
Manufacturing and Processing
1. Selección de materiales
-
Alta calidad 304, 304l, o 316 acero inoxidable is used for corrosion resistance and long service life.
2. Tube Forming
-
Sin costura (SMLS) o soldado (ACRE) pipes are used depending on wall thickness and application.
-
Round pipes are the most common for drainage, while rectangular or oval profiles may be used in architectural drainage systems.
3. Tratamiento superficial
-
Pickling and passivation remove mill scale and enhance corrosion resistance.
-
Pulido (satin or mirror finish) improves water flow and hygiene.
4. Cutting and End Finishing
-
Pipes are cut to standard or custom lengths.
-
Ends can be plain, flanged, or threaded depending on installation requirements.
5. Inspection
-
Dimensional checks for DE, espesor de pared, and straightness
-
Surface quality inspection to ensure smooth internal and external surfaces
Aplicaciones
-
Residential and commercial wastewater drainage
-
Rainwater and stormwater systems
-
Industrial chemical drainage
-
Kitchen and food processing drainage
-
Tuberías de residuos farmacéuticos y de laboratorio.
Ventajas
-
Resistente a la corrosión y al óxido
-
Higiénico y fácil de limpiar
-
Durable y duradero
-
Disponible en varios tamaños y acabados
-
Compatible con estándares de tuberías soldadas y sin costura
