Checkered Plate Stainless Steel
Checkered plate stainless steel is available in a wide range of standard sizes, typically from 1000 مم ل 1500 mm in width and up to 6000 mm in length, with thickness options from 2 mm to over 10 مم.
- وصف
Checkered plate stainless steel is a textured stainless steel sheet with raised patterns such as diamond or checker designs. It is widely used for anti-slip flooring, معالجته الدرج, ramps, and industrial platforms due to its combination of strength, متانة, ومقاومة التآكل.
نطاق السماكة المشتركة
The thickness of checkered stainless steel plate is one of the most important specifications, as it determines load capacity and application type.
- Light-duty applications: 2.0 مم - 3.0 مم
- Standard industrial use: 3.0 مم - 6.0 مم
- Heavy-duty flooring: 6.0 مم - 10.0 مم
- Special structural applications: above 10.0 مم (less common)
أحجام الأوراق القياسية
Checkered stainless steel plates are typically supplied in standard sheet dimensions for easy fabrication and transportation.
Common Width and Length
- 1000 مم × 2000 مم
- 1219 مم × 2438 مم (4 قدم × 8 قدم)
- 1500 مم × 3000 مم
- 1500 مم × 6000 مم
Custom cutting sizes are also widely available based on project requirements.
Pattern Specifications
Different checkered patterns also influence usability and application performance.
- نمط الماس: most common industrial standard
- Five-bar pattern: high slip resistance for heavy-duty use
- Small checker pattern: lighter applications and decorative use
- Customized embossing patterns: architectural or special design needs
Material Grades Commonly Used
Checkered stainless steel plates are typically produced in standard austenitic grades:
- 304: general-purpose, مقاومة جيدة للتآكل
- 304ل: improved weldability
- 316: higher corrosion resistance, suitable for marine environments
- 316ل: low carbon version for enhanced corrosion performance
خيارات إنهاء السطح
- Mill finish (standard industrial surface)
- لمسة نهائية مصقولة (uniform directional texture)
- Polished finish (improved appearance for architectural use)
Tolerance and Fabrication Standards
- Thickness tolerance depends on production process (hot rolled or embossed)
- Flatness varies based on pattern depth
- Edges can be supplied as mill edge or cut edge
- Suitable for cutting, لحام, الانحناء, وتشكيل
