Chapa Xadrez Inox
Checkered plate stainless steel is available in a wide range of standard sizes, typically from 1000 mm para 1500 mm in width and up to 6000 mm in length, with thickness options from 2 mm to over 10 milímetros.
- Descrição
Checkered plate stainless steel is a textured stainless steel sheet with raised patterns such as diamond or checker designs. It is widely used for anti-slip flooring, degraus de escada, rampas, and industrial platforms due to its combination of strength, durabilidade, e resistência à corrosão.
Faixa de espessura comum
The thickness of checkered stainless steel plate is one of the most important specifications, as it determines load capacity and application type.
- Light-duty applications: 2.0 milímetros – 3.0 milímetros
- Standard industrial use: 3.0 milímetros – 6.0 milímetros
- Heavy-duty flooring: 6.0 milímetros – 10.0 milímetros
- Special structural applications: above 10.0 milímetros (less common)
Tamanhos de folha padrão
Checkered stainless steel plates are typically supplied in standard sheet dimensions for easy fabrication and transportation.
Common Width and Length
- 1000 milímetros × 2000 milímetros
- 1219 milímetros × 2438 milímetros (4 pés × 8 pés)
- 1500 milímetros × 3000 milímetros
- 1500 milímetros × 6000 milímetros
Custom cutting sizes are also widely available based on project requirements.
Pattern Specifications
Different checkered patterns also influence usability and application performance.
- Diamond pattern: most common industrial standard
- Five-bar pattern: high slip resistance for heavy-duty use
- Small checker pattern: lighter applications and decorative use
- Customized embossing patterns: architectural or special design needs
Material Grades Commonly Used
Checkered stainless steel plates are typically produced in standard austenitic grades:
- 304: general-purpose, boa resistência à corrosão
- 304eu: soldabilidade melhorada
- 316: maior resistência à corrosão, suitable for marine environments
- 316eu: low carbon version for enhanced corrosion performance
Opções de acabamento de superfície
- Mill finish (superfície industrial padrão)
- Acabamento escovado (uniform directional texture)
- Acabamento polido (improved appearance for architectural use)
Tolerance and Fabrication Standards
- Thickness tolerance depends on production process (hot rolled or embossed)
- Flatness varies based on pattern depth
- Edges can be supplied as mill edge or cut edge
- Suitable for cutting, soldagem, flexão, e formando
